How ExtendaLoader Works

Revolutionary telescoping boom technology that extends reach without compromising stability

Core Technology

ExtendaLoader modifies the conventional two-legged boom assembly by separating the distal and proximal boom legs at the natural "knee" point. This creates a telescoping mechanism that can extend up to 3 feet while maintaining full structural integrity.

Operation Principle

The system operates like a telescope - extending when additional reach is needed, then retracting to original compact form. Hydraulic cylinders provide smooth, controlled extension and retraction while maintaining precise boom orientation.

Key Components

Feature	Standard Front-End Loader	ExtendaLoader Enhanced
Maximum Reach	Fixed based on boom length	+3 feet additional reach
Vertical Clearance	Limited by boom geometry	Enhanced by extendable capability
Structural Integrity	Rigid hollow boom design	Improved through engineering design and additional structural steel
Control Complexity	Standard hydraulic controls	Uses existing tractor hydraulic controls
Retracted Performance	Standard operation	Identical to standard loader

Specs

Technical Specifications

Extension Capabilities

Maximum Extension 3 feet (0.91m)

Extension per Leg Up to 3 feet

Extension Pattern Doglegged trajectory

Wheel Clearance Full clearance maintained

Materials & Construction

Primary Material Carbon Steel

Wear Pads Industry-standard materials

Finish Options Standard tractor finishes

Fasteners Grade 8 hardware

Hydraulic Requirements

Cylinder Type Standard hydraulic

Mounting Options External

Flow Control 4-section rotary gear divider (optional)

Pressure Rating Standard tractor hydraulics

Safety & Performance

Load Capacity Maintains original specs

Safety Factor Engineering validated

Extension Limits Built-in mechanical stops

(903) 235-9090

Manufacturing Integration

Streamlined process for incorporating ExtendaLoader into existing production lines

Boom Modification

Separate existing boom legs at the natural knee point. Fabricate female telescoping section into proximal leg and male section for distal boom.

Hydraulic Integration

Install external hydraulic cylinders and connect to existing tractor hydraulic system using standard components.

Wear Protection

Install industry standard nylon wear pads inside proximal leg section with standard fasteners.

Control Connection

Connect extension controls to existing tractor hydraulic controls – no additional control interfaces required.

Quality Validation

Standard testing procedures verify extension limits, load capacity, and safety features before final assembly.

Final Assembly

Complete assembly using existing processes – ExtendaLoader integrates seamlessly with current workflows.

Key Integration Benefits

Minimal process changes
Existing supplier network
Uses standard materials
Standard quality procedures
Familiar maintenance requirements

International: Available for Filing

Patent Protection

ExtendaLoader technology is fully protected by issued U.S. patent, providing licensing partners with exclusive market advantages

Join the agricultural innovation leaders. License ExtendaLoader technology today.

"*" indicates required fields

Prefer to talk directly?

903-235-9090

Monday-Friday, 8 AM - 6 PM CST
Serious licensing inquiries only

Ready for a Technical Evaluation?

Our engineering team is ready to discuss integration specifics with your technical staff
